Measures and specifications of hinged door cm 60x220

Invisible hinged door h 210 with invisible handle

Hinged door cm 60×220

Name: Hinged door cm 60x220 | Invisible-door
SKU: HD60X220
Availability: InStock

Door hand

Handle

Door finish

Wall

Advance shipment of frames

Clear

Lacquering - RAL color

RAL, NCS or Pantone code

Enter the RAL, NCS or Pantone code (example: RAL 9001)

Free shipping

VAT included

2 year warranty

100% Made in Italy

ATTENTION

Days from August 8 to 31 are excluded from shipping times.

free
shipping

VAT
included

2-year
warranty

100% MADE
IN ITALY

measures and specifications

technical sheet

QUESTIONS & INFORMATION

How to choose the opening direction of our flush-to-wall hinged door:

🚪Imagine you are standing in front of the door, on the flush-to-wall side (outside the room).

🚪If the hinges are on the right, the door opens to the right; if they are on the left, it opens to the left.

🚪If you push the door to enter → it is a push door.

🚪If you pull the door toward you → it is a pull door.

How to recognize the flush side of the door:

🚪 Our flush-to-wall hinged door has two sides:

a flush side, perfectly flush with the wall, with no visible thickness;
a non-flush side, where the thickness of the wall is visible.

🧱 Usually, the flush side is the one outside the room or alcove.

✨ Its strength lies in its invisible effect, because the door and the wall appear to be a single surface.

✅ You can install it during renovation work or even after the work is completed, on walls and floors that are already finished.

🧱 Installation can be carried out by: a construction company overseeing the work; a plasterboard worker responsible for constructing walls, wall returns, and suspended ceilings; a skilled craftsman experienced in door and frame installation, or a competent DIYer familiar with drywall work, joint filling, and taping.

ℹ️ For more information, go to the section dedicated to installing invisible flush-to-wall doors.

What is included in an order for a flush-to-wall hinged door:

🪵 Factory pre-assembled frame, supplied complete with stop gasket.

🚪 53 mm door leaf, treated with primer and ready for painting, for a perfect invisible effect.

🔒 AGB Revolution XT magnetic lock, already mounted in the door leaf.

🕳️ Holes for handle installation already drilled at the factory.

⚙️ 3 invisible hinges adjustable in 4 directions, with a load capacity of up to 100 kg and compatible with cladding up to 1.5 cm thick.

Features of the invisible frame:

🏭 Always pre-assembled in the factory, ready for installation.

📏 Equipped with spacers to keep it perfectly straight.

🦾 Designed and extruded to ensure high mechanical resistance.

✨ Satin silver finish with black brush seal included.

🎨 Available on request painted to sample (RAL, NCS, Pantone) or in special finishes.

LEARN MORE →

Features of the invisible door-leaf:

🌲 Structure with solid fir wood battens and anti-warp aluminum profiles, invisible from the outside.

🪵 Covered in sanded and edged MDF, ready for a perfect finish.

📢 45 mm thick sound-absorbing polystyrene filling.

🔩 Pre-drilled for hinge installation.

🎨 Treated with primer over the entire surface.

❌ We do not use laminate!

LEARN MORE →

Invisible door hinges:

🔩 Steel hinges from French brand Cemom®, a guarantee of quality and durability.

👁️ Invisible when the door is closed, for a clean and minimalist look.

⚙️ Adjustable in 4 directions for perfect alignment.

🚪 Opens up to 180° (only for pull doors).

💪 Certified load capacity:

up to 96 kg for doors up to 220 cm high;
up to 130 kg for doors up to 300 cm high.

LEARN MORE →

Invisible door lock:

🔒 All our flush-to-wall hinged doors are fitted with a high-quality magnetic lock, 100% Made in Italy.

🧲 The magnetic movement ensures silent closing, smooth opening, and no scratches on the frame.

🛠 The lock is already installed in the door leaf and can be chosen with a patent key or privacy latch, depending on the configuration.

🕳️ The drilling of holes in the door leaf is free of charge and can be chosen according to your needs.

Handles and locking systems:

🖐️ During configuration, you can choose among different types of handles.

⚙️ Alternatively, you can request pre-drilled holes to install a handle purchased elsewhere.

🔒 Each handle can be combined with the desired locking system: patent key or privacy latch.

LEARN MORE →

Lacquering of the flush-to-wall door leaves:

🎨 Our lacquer finish is always soft-touch and matte, with a smooth, uniform surface (glossy lacquer finish is not available).

🌈 The lacquer finish is available in all RAL, NCS, or Pantone colors.

🪄 This allows you to customize the door to match the style of your home.

follow the assembly steps

installation

We have prepared a video showing you all the steps to properly install an invisible hinged door. Watch it all for visual and practical guidance.

click on the video

Who can install?

The installation of our hinged doors can be carried out by:

Construction company carrying out renovation work;
Plasterer contractor who is in charge of making the walls or the or ceilings;
Craftsman who has experience in installing window frames and interior doors;
🔨 DO-IT-YOURSELF, only recommended if you have experience with plasterboard wall construction, including plastering and gauzing

When can it be installed?

The installation of our hinged doors can be carried out by:

During work: you can have the flush door installed during renovation work;
Once the work is done: the door can also be installed on finished walls with completed floors and ceilings, as shown in the video.
